MP-Current Transformer-1659

Accurate, Flexible & Easy‑Install Current Measurement Solution

The China Moneypro Current Transformer is a reliable and precise current sensing accessory designed for energy monitoring and export/import measurement in solar and energy storage systems. With wide current adaptability, a split‑core design, and safe operation, it enables accurate current measurement for dynamic energy management.

High‑Precision Current Sensing

Capture Real‑Time Current Data

• Supports a primary current range from 100 A to 600 A to suit different system sizes.

• Outputs a stable 40 mA secondary current for reliable measurement.

• Works with smart energy meters and power management devices to provide precise flow and consumption data.

Benefits:

• Accurate current detection improves grid export/import control.

• Data reliability supports energy monitoring and system optimization.

Flexible & Easy Installation

Designed for Field Convenience

• Split‑core structure enables installation without disconnecting main conductors.

• Multiple rated current options (100 A, 200 A, 400 A, 600 A) provide flexibility for different system requirements.

• Compatible with a wide range of monitoring devices and hybrid/energy management systems.

Advantages:

• Quick installation reduces labor and setup time.

• One‑device solution for varied PV and ESS configurations.

Safe & Reliable Operation

Built for Long‑Term Measurement

• Designed for safe and stable current sensing with minimal interference.

• Suitable for use in residential, commercial, and industrial energy systems where accurate current feedback is essential.

Advantages:

• Robust performance in diverse electrical environments.

• Ensures precise measurement for energy analytics and control.

Typical Applications

• PV Energy Systems: Used for solar generation monitoring and export control.

• Hybrid & Energy Storage: Supports battery charge/discharge management and consumption analytics.

• Load Monitoring: Measures household or site consumption for dynamic management and optimization.

• Smart Energy Management: Integrates with cloud or local energy monitoring platforms for real‑time insights.

Why Choose China Moneypro Current Transformer?

• Wide Current Range: Flexible primary current support from 100 A to 600 A.

• Stable Output: Standard 40 mA secondary output for precise detection.

• Easy Setup: Split‑core design for fast, non‑intrusive installation.

• Versatile Compatibility: Works with smart meters and energy management systems.

• Reliable Measurement: Ensures accurate current data for export/import control and energy analysis.

FAQ – Common Questions

Q1: What does a current transformer (CT) do?
A CT measures alternating current by converting a large primary current into a smaller, standardized secondary current used for sensing and analytics.

Q2: Why is this CT needed in a solar/ESS system?
CTs provide accurate current measurements for export control, self‑consumption tracking, and battery management in hybrid or grid‑connected systems.

Q3: How is the CT installed?
The split‑core design allows installers to clamp the device around the conductor without disconnecting power lines.

Q4: What primary current ratings are available?
Current options include 100 A, 200 A, 400 A, and 600 A with a consistent 40 mA secondary output.

Q5: Can one CT be used for different meters or devices?
Yes — with proper compatibility settings and correct installation, the CT can work with various smart meters and monitoring units to provide accurate current feedback.
